JWDTools (Engineering Tools)

Description of JWDTools (Engineering Tools)

JWDTools program is especially useful for civil and structural engineers.
It includes a set of engineering and mathematical tools as well as a unit conversion section.
The calculation and design in engineering tools section is done according to the ultimate method of the Syrian Arab code.
Tools in the current version are
:
Structural Engineering Tools:
• Section Designer: Bending Design (Rect - T) - Shear Design - Beaxial Design and Interaction Diagram.
• Element Designer: Column - Isolated Footing - Corbel
• Simplified Structural Analysis: Continuous Beam - Seismic Forces (UBC97 - ASCE 7/2010)
• Dimension Estimation: Beam Depth - One Way Slab Thickness - Two Way Slab Thickness - Ribbed Slab Thickness
• Steel Bars: Bars Table - Bars Calculator - Stirrups Calculator - Mesh Weight
• Section Properties: Many section shapes (I - C - T - L - Rectangle - Circle - Ring ... etc)
• Other: Concrete Properties - Volume Weight of Materials - Hordy Blocks Weight
Mathematical Tools:
• Equations: Solving Equation of n Degree - System of Linear Equations
• Geometry (2D): Calculation of Lengths, Perimeter and Area (Contains Triangle Solver and Irregular Quadratic Shape)
• Geometry (3D): Calculation of Lengths, Area and Volume
• Algebra: Fractions and Decimals - GCD / LCM - Primary Factors
Conversion Tools:
• Conversion of units to a wide range of quantities
--------------------------------------
This program is bilingual (Arabic and English), and can be switched between these two languages ​​through the program options.
Some of tools are free, some require full version activation (paid)
How to activate the full version is shown here:
http://www.jwdstructure.com/products/jwdtools_mobile/activation.htm
The explanation of the tools contained in the program is shown here:
http://www.jwdstructure.com/learning/tutorials/jwdtools_mobile/index.htm
This program is a member of the family of JWDStructure © series that includes:
• JWDBeam: Continuous Beam Analysis and Design
• JWDQuake: Seismic Design Program
• JWDColumn: Columns and Foundations Design
